2SF10SEEL Cat Pump 1 GPM / 3.8 LPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
Operates under 12VDC, 24VDC or 115/230V
CAT Pumps 2SF10SEEL 2SF-Series Plunger Pump
The CAT Pumps 2SF10SEEL is a highly efficient, industrial-duty direct-drive triplex plunger pump belonging to the renowned 2SF Series. Engineered for high-pressure fluid transfer in highly corrosive and demanding environments, this positive displacement pump features a wetted end constructed entirely of 316 Stainless Steel. This premium metallurgy ensures maximum structural integrity, exceptional chemical compatibility, and long-lasting durability, making it the industry standard for continuous-duty applications such as reverse osmosis, seawater desalination, industrial misting, and specialized chemical injection systems.
Designed to deliver precise and reliable performance, the 2SF10SEEL operates at a steady flow rate of 1.0 GPM with a maximum pressure capacity of 1200 PSI. It incorporates advanced, concentric solid ceramic plungers that provide a true, low-friction wear surface, substantially extending the operational life of the standard NBR (Buna-N) seals. Utilizing a space-saving, hollow-shafted configuration, this pump is designed to bolt directly to a standard 56C-face electric motor. By eliminating the need for external belts, pulleys, and mounting plates, this compact direct-drive assembly delivers the highly consistent, continuous-duty operation required for mission-critical liquid handling systems.
| SPECIFICATION | DETAILS |
| Model Number | 2SF10SEEL |
| Manufacturer | CAT Pumps |
| Pump Type | Triplex Plunger Pump |
| Manifold Material | 316 Stainless Steel |
| Max Flow Rate | 1.0 GPM (3.8 LPM) |
| Pressure Range | 100 – 1200 PSI |
| Test Pressure | 1200 PSI |
| Max Pump Speed | 1725 RPM |
| Inlet Port Size | 3/8" NPT(F) |
| Discharge Port Size | 3/8" NPT(F) |
| Shaft Diameter | 5/8" (15.9 mm) Hollow |
| Max Liquid Temp (NBR) | 160°F (71°C) |
| Pump model | Flow | Pressure | Manifold material | RPM | HP | kW | ||
| GPM | LPM | PSI | BAR | |||||
| 2SF10SEEL | 1 | 3.8 | 1200 | 83 | SS | 1725 | 0.8 | 0.6 |
