CAT Pumps 2SFQ29SEEL.0110 2SFQ-Series Plunger Pump



The CAT Pumps 2SFQ29SEEL.0110 is an industrial-duty, direct-drive triplex plunger pump from the highly regarded 2SFQ Series. Engineered to deliver highly reliable fluid transfer while significantly reducing operational noise, this "Quiet" series positive displacement pump features a wetted end constructed entirely of 316 Stainless Steel. This premium manifold metallurgy ensures exceptional structural integrity and high chemical compatibility, making it an ideal choice for continuous-duty applications such as large industrial reverse osmosis, seawater desalination, and specialized pressure washing where both durability and lower decibel levels are prioritized.

Designed to maximize uptime and operational efficiency, this specific model features a precision-engineered 5/8" hollow shaft configuration that allows it to bolt directly to a standard NEMA 56C-face electric motor, eliminating the need for external belts, pulleys, and mounting plates. It operates at a consistent flow rate of 2.85 GPM with a maximum pressure capacity of 1200 PSI. The ".0110" designation indicates that this unit is factory-equipped with FPM (Fluorocarbon / Viton) seals and O-rings, which safely extends the maximum allowable liquid temperature to 180°F. By combining high-temperature tolerance, a true wear surface via solid ceramic plungers, and a compact footprint, this plunger pump delivers consistent, reliable performance for high-purity and thermally demanding fluid systems.



SPECIFICATION DETAILS
Model Number 2SFQ29SEEL.0110
Manufacturer CAT Pumps
Pump Type Triplex Plunger Pump
Manifold Material 316 Stainless Steel
Max Flow Rate 2.85 GPM (10.8 LPM)
Pressure Range 100 - 1200 PSI
Test Pressure 1200 PSI
Max Pump Speed 1725 RPM
Inlet Port Size 3/8" NPT(F)
Discharge Port Size 3/8" NPT(F)
Shaft Diameter 5/8" (15.9 mm) Hollow
Seal Material FPM (Fluorocarbon / Viton)
Max Liquid Temp (FPM) 180°F (82°C)
