Cat Pumps 1810 Stainless Steel Block-Style Triplex Plunger Pump (3.0 GPM, 10,000 PSI)
The Cat Pumps 1810 is an industrial-duty, 18-frame triplex plunger pump engineered for demanding, ultra-high-pressure applications. As verified by the manufacturer, this heavy-duty positive displacement pump is highly recommended for professional high-pressure washing, concrete hydro-demolition, and industrial paint stripping. It features a precision-machined, block-style 304 stainless steel manifold that provides exceptional structural strength and corrosion resistance during sustained, cyclic pressure loading. The wet-end utilizes concentric, high-density, polished solid ceramic plungers to provide a true wear surface and significantly extend seal life in harsh operational environments.
Designed for uncompromising durability and continuous-duty performance, the 1810 model delivers a highly consistent flow rate of 3.0 gallons per minute (GPM) while operating at an ultra-high test pressure of 10,000 PSI. It utilizes special UHMW (Ultra-High Molecular Weight) supported V-packings to maintain stability under extreme pressure forces. The die-cast aluminum crankcase features an oversized chrome-moly crankshaft and oversized bearings, maximizing load capacity and ensuring optimum oil bath lubrication. With its simple wet-end access that allows for servicing without entering the crankcase, this pump minimizes maintenance downtime for heavy-duty commercial pressure washing systems.
| SPECIFICATION | DETAILS |
| Model Number | 1810 |
| Manufacturer | Cat Pumps |
| Pump Type | Triplex Plunger Pump |
| Manifold Material | 304 Stainless Steel (Block-Style) |
| Max Flow Rate | 3.0 GPM (11.4 lpm) |
| Max Applied / Test Pressure | 10,000 PSI (689 bar) |
| Max Pump Speed | 1500 RPM |
| Max Liquid Temp | 160°F (71°C) |
| Inlet Port Size | 1/2" NPT(F) |
| Discharge Port Size | 3/8" NPT(F) |
| Stroke | 1.181" (30 mm) |
| Bore | 0.433" (11 mm) |
| Crankcase Capacity | 42 oz (1.24 L) |
