Cat Pumps
2SF35SEEL Cat Pump 3.5 GPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
2SF35SEEL Cat Pump 3.5 GPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
Couldn't load pickup availability
2SF35SEEL Cat Pump 3.5 GPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
-
FREE SHIPPING to The Contiguous United States! (Excluding Alaska & Hawaii)
-
In Stock & Ships from The United States!
-
Financing Options Available at Checkout via Shop Pay!
-
For Quantity Discounts Contact Us for a Quote!
-
Customers Outside The Contiguous United States, Please Contact Us for a Quote!
-
Call: 1 (760) 598-0189
-
Email: hctivista@gmail.com
PLEASE REFERENCE TABLE BELOW
CAT Pumps 2SF35SEEL 2SF-Series Plunger Pump
The CAT Pumps 2SF35SEEL is a highly efficient, industrial-duty direct-drive triplex plunger pump belonging to the renowned 2SF Series. Engineered for high-pressure fluid transfer in highly corrosive and demanding environments, this positive displacement pump features a wetted end constructed entirely of 316 Stainless Steel. This premium metallurgy ensures maximum structural integrity, exceptional chemical compatibility, and long-lasting durability, making it an industry standard for continuous-duty applications such as reverse osmosis, seawater desalination, industrial misting, and specialized chemical injection systems.
Designed to deliver precise and reliable performance, the 2SF35SEEL operates at a steady flow rate of 3.5 GPM with a maximum pressure capacity of 1200 PSI. It incorporates advanced, concentric solid ceramic plungers that provide a true, low-friction wear surface, substantially extending the operational life of the standard NBR (Buna-N) seals. Utilizing a space-saving, hollow-shafted configuration, this pump is designed to bolt directly to a standard 56C-face electric motor. By eliminating the need for external belts, pulleys, and mounting plates, this compact direct-drive assembly delivers the highly consistent, continuous-duty operation required for mission-critical liquid handling systems.
| SPECIFICATION | DETAILS |
| Model Number | 2SF35SEEL |
| Manufacturer | CAT Pumps |
| Pump Type | Triplex Plunger Pump |
| Manifold Material | 316 Stainless Steel |
| Max Flow Rate | 3.5 GPM (13.2 LPM) |
| Pressure Range | 100 - 1200 PSI |
| Test Pressure | 1200 PSI |
| Max Pump Speed | 1725 RPM |
| Inlet Port Size | 3/8" NPT(F) |
| Discharge Port Size | 3/8" NPT(F) |
| Shaft Diameter | 5/8" (15.9 mm) Hollow |
| Max Liquid Temp (NBR) | 160°F (71°C) |
