2SFQ35SEEL Cat Pump 3.5 GPM / 13.2 LPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
2SFQ35SEEL Cat Pump 3.5 GPM / 13.2 LPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
Couldn't load pickup availability
- FREE SHIPPING to The Contiguous United States! (Excluding Alaska & Hawaii)
- Found a Better Price? Contact Us, We'll See if We Can Get You a Better Deal!
- In Stock & Ships from The United States FAST!
- For Quantity Discounts Contact Us for a Quote!
- Customers Outside The Contiguous United States, Please Contact Us for a Quote!
- Call: 1 (760) 598-0189
- Email: hctivista@gmail.com
SFQ35SEEL Cat Pump 3.5 GPM / 13.2 LPM 1200 PSI 1725 RPM Direct Drive 316 Stainless Steel
CAT Pumps 2SFQ35SEEL 2SFQ-Series Plunger Pump
The CAT Pumps 2SFQ35SEEL is a specialized, industrial-duty direct-drive triplex plunger pump from the highly regarded 2SFQ Series. Engineered to deliver highly reliable fluid transfer while significantly reducing operational noise, this "Quiet" series positive displacement pump features a wetted end constructed entirely of 316 Stainless Steel. This premium manifold metallurgy ensures exceptional structural integrity and high chemical compatibility, making it an ideal choice for continuous-duty applications such as large industrial reverse osmosis, seawater desalination, and specialized chemical injection systems where both corrosion resistance and lower decibel levels are critical priorities.
Designed to maximize uptime and operational efficiency, this model utilizes a precision-engineered 5/8" hollow shaft configuration that allows it to bolt directly to a standard NEMA 56C-face electric motor, completely eliminating the need for external belts, pulleys, and mounting plates. It operates at a consistent flow rate of 3.5 GPM with a maximum pressure capacity of 1200 PSI. Factory-equipped with standard NBR (Buna-N) seals and O-rings, the pump safely accommodates continuous liquid temperatures up to 160°F. By combining a true low-friction wear surface via concentric solid ceramic plungers with a compact, noise-reducing footprint, this plunger pump delivers consistent, reliable performance for high-purity fluid systems.
| SPECIFICATION | DETAILS |
| Model Number | 2SFQ35SEEL |
| Manufacturer | CAT Pumps |
| Pump Type | Triplex Plunger Pump ("Quiet" Series) |
| Manifold Material | 316 Stainless Steel |
| Max Flow Rate | 3.5 GPM (13.2 LPM) |
| Pressure Range | 100 - 1200 PSI |
| Test Pressure | 1200 PSI |
| Max Pump Speed | 1725 RPM |
| Inlet Port Size | 3/8" NPT(F) |
| Discharge Port Size | 3/8" NPT(F) |
| Shaft Diameter | 5/8" (15.9 mm) Hollow |
| Seal Material | NBR (Medium Nitrile / Buna-N) |
| Max Liquid Temp (NBR) | 160°F (71°C) |
| Pump model | Flow | Pressure | Manifold material | RPM | HP | kW | ||
| GPM | LPM | PSI | BAR | |||||
| 2SFQ35SEEL | 3.5 | 13.2 | 1200 | 83 | SS | 1725 | 2.9 | 2.1 |
