2SFQ42SEEL Cat Pump 4.2 GPM / 15.9 LPM 1200 PSI 316 Stainless Steel 1725 RPM Direct Drive 3/8" NPT(F) Inlet & Discharge Port Size

2SFQ42SEEL Cat Pump 4.2 GPM / 15.9 LPM 1200 PSI 316 Stainless Steel 1725 RPM Direct Drive 3/8" NPT(F) Inlet & Discharge Port Size

Regular price $1,499.99 USD
Regular price Sale price $1,499.99 USD
Sale Sold out
Quantity
  • FREE SHIPPING to The Contiguous United States! (Excluding Alaska & Hawaii)
  • Found a Better Price? Contact Us, We'll See if We Can Get You a Better Deal!
  • In Stock & Ships from The United States FAST!
  • For Quantity Discounts Contact Us for a Quote!
  • Customers Outside The Contiguous United States, Please Contact Us for a Quote!
  • Call: 1 (760) 598-0189
  • Email: hctivista@gmail.com

We are an Authorized Distributor for Cat Pumps



Engineered for demanding continuous-duty applications such as reverse osmosis, desalination, and highly corrosive fluid transfer, the Cat Pumps 2SFQ42SEEL is a commercial-grade, direct-drive triplex plunger pump. To ensure maximum chemical and corrosion resistance, this pump features a specialized "wet end" constructed entirely of 316 stainless steel, encompassing both the manifold and valve assemblies. Unlike standard forged brass pumps, this high-grade stainless steel construction provides the essential structural integrity and longevity required when pumping harsh seawater or aggressive industrial chemicals.

While the fluid-contact components are precision-machined from 316 stainless steel, the pump integrates a variety of specialized materials to maximize overall performance, durability, and cost-efficiency. It utilizes a lightweight aluminum crankcase to effectively dissipate heat, along with solid ceramic plungers that provide a true, low-friction wear surface to significantly extend the lifespan of the standard NBR (Buna-N) seals and O-rings. Furthermore, the "Q" in the model number designates a specialized internal design that reduces operating sound levels by up to 6 decibels, making it ideal for indoor or noise-sensitive installations. Operating at 1725 RPM, this compact positive displacement pump mounts seamlessly to a standard NEMA 56C face electric motor via a 5/8-inch hollow shaft, delivering a highly consistent flow rate of 4.2 gallons per minute (GPM) at a robust test pressure of 1200 PSI.



Specification Details Notes
Manufacturer Cat Pumps
Model Number 2SFQ42SEEL
Pump Type Triplex Plunger Pump Positive Displacement (Direct-Drive)
Manifold Material (Wet End) 316 Stainless Steel Exceptional corrosion resistance
Valve Material 316 Stainless Steel
Crankcase Material Aluminum Heat dissipation
Plunger Material Solid Ceramic
Seal Material NBR (Buna-N) Standard
Max Flow Rate 4.2 GPM (15.9 LPM)
Pressure Range 100 - 1200 PSI
Test Pressure (Applied) 1200 PSI (83 bar) High-pressure operation
Max Pump Speed 1725 RPM
Shaft Diameter 5/8" Hollow Shaft
Motor Mount NEMA 56C Face Direct electric motor mount
Inlet Port Size 3/8" NPT(F)
Discharge Port Size 3/8" NPT(F)
Max Liquid Temp (NBR) 160°F (71°C)
Sound Reduction -6 dBa "Q" model feature
Primary Applications Reverse Osmosis, Desalination, Chemical Corrosive fluid transfer
