Cat Pumps
3531DHS.0770 Cat Pump 36 GPM 1200 PSI 316 SS Triplex Positive Displacement Plunger 35-Frame , Block-Style Manifold , High Strength Connecting Rods and Plunger Rods , Specialty Pure PTFE (Teflon) Seal Option , O-Rings: FFKM (Isolast)
Couldn't load pickup availability
- FREE SHIPPING to The Contiguous United States! (Excluding Alaska & Hawaii)
- Found a Better Price? Contact Us, We'll See if We Can Get You a Better Deal!
- IN STOCK & SHIPS FAST from The United States!
- For Quantity Discounts Contact Us for a Quote!
- Customers Outside The Contiguous United States, Please Contact Us for a Quote!
- Call: 1 (760) 598-0189
- Email: hctivista@gmail.com
3531DHS.0770 Cat Pump 36 GPM 1200 PSI 316 Stainless Steel Triplex Positive Displacement Plunger 35-Frame , Block-Style Manifold , High Strength Connecting Rods and Plunger Rods , Specialty Pure PTFE (Teflon) Seal Option , O-Rings: FFKM (Isolast)
CAT Pumps 3531DHS.0770 Industrial Plunger Pump
The CAT Pumps 3531DHS.0770 is a specialized Industrial Triplex Plunger Pump engineered for extreme chemical compatibility and high-temperature applications. Based on the robust 35-Frame "HS" (High Strength) platform, this unit features a 316 Stainless Steel manifold that offers superior corrosion resistance against aggressive fluids, deionized water, and chemical solutions that would destroy standard brass pumps.
The ".0770" suffix indicates a factory-installed high-performance seal configuration. This model is equipped with Pure PTFE (Teflon®) high/low-pressure seals and FFKM (Isolast®) O-rings. This specialized sealing system allows the pump to handle harsh solvents and high fluid temperatures up to 200°F (93°C), significantly higher than the standard NBR rating. With a continuous duty rating of 36 GPM at 1,200 PSI, it is the premier choice for chemical injection, aggressive fluid transfer, and high-temp industrial cleaning systems.
Product Accuracy & Specifications: While we make every effort to ensure the accuracy of the information provided, Hydrocomponents & Technologies Inc. assumes no responsibility for errors, omissions, or typographical errors in product descriptions or specifications. Product specifications, including dimensions, materials, and performance ratings, are provided by the manufacturers and are subject to change without notice. Please consult the manufacturer's official documentation for the most current data before purchase.
| SPECIFICATION | DETAILS |
| Model Number | 3531DHS.0770 |
| Manufacturer | CAT Pumps |
| Pump Type | Triplex Plunger Pump |
| Manifold Material | 316 Stainless Steel |
| Seal Configuration (.0770) | Pure PTFE Seals / FFKM (Isolast) O-Rings |
| Max Flow Rate (Continuous) | 36 GPM (136 L/m) |
| Max Operating Pressure | 1200 PSI (83 Bar) |
| Intermittent Rating | 40 GPM @ 2000 PSI (Limited Duty) |
| RPM | 800 RPM |
| Max Liquid Temp | 200°F (93°C) |
| Inlet Port Size | 1-1/2" NPT(F) |
| Discharge Port Size | 1" NPT(F) |
| Shaft Diameter | 35 mm (Solid Shaft) |
| Oil Capacity | 4.2 Qts (4 L) |
| Weight | 139 lbs (63 kg) |
