5CP3160CSSG1 CAT Pressure Washer Triplex Positive Displacement Plunger Pump 4 GPM 3500 PSI , 316 Grade Stainless Steel Manifold , Mounts to 1" Gas Engine Shaft , Forged Brass Block , Standard Buna-N O-rings and Seals
CAT Pumps 5CP3160CSSG1 Plunger Pump
The CAT Pumps 5CP3160CSSG1 is a specialized Triplex Plunger Pump assembly equipped with a gearbox, widely recognized as a premium upgrade for commercial pressure washers. Unlike standard brass pumps, this model features a 316 Stainless Steel manifold and solid ceramic plungers, providing superior resistance to corrosive detergents, saltwater, and harsh chemical environments often encountered in industrial cleaning.
Designed for heavy-duty applications, this unit features a 1" hollow shaft gearbox that bolts directly to 11.7 HP – 13.4 HP gas engines (such as the Honda GX390). The integrated gearbox reduces the engine speed to a lower, optimal pump RPM, minimizing heat and wear for extended service life. As a true Positive Displacement Pump, it delivers a verified flow rate of 4.0 GPM at 3,500 PSI, offering the high-impact cleaning power required for fleet washing, sanitation, and facility maintenance.
| SPECIFICATION | DETAILS |
| Model Number | 5CP3160CSSG1 |
| Manufacturer | CAT Pumps |
| Pump Type | Triplex Plunger Pump |
| Displacement Type | Positive Displacement |
| Drive Type | Gearbox (Bolt-on) |
| Material (Manifold) | 316 Stainless Steel |
| Material (Valves) | 316 Stainless Steel |
| Max Flow Rate | 4.3 GPM (16.3 LPM) |
| Applied Pressure (Test) | 3500 psi |
| Max Operating Pressure | 3500 psi |
| Max Liquid Temp | 160°F (71°C) |
| Inlet Port Size | 1/2" NPT(F) |
| Discharge Port Size | 3/8" NPT(F) |
| Engine Shaft Requirement | 1" Horizontal Shaft |
| Pump RPM | 1725 |
