7CP6110CSG1 Cat Pressure Washer Triplex Positive Displacement Pump 10 GPM 2000 PSI , Gearbox Mounts to a 1" Gas Engine Shaft , Brass Block , Buna-N O-rings and Seals
7CP6110CSG1 Cat Pressure Washer Triplex Positive Displacement Pump 10 GPM 2000 PSI , Gearbox Mounts to a 1" Gas Engine Shaft , Brass Block , Buna-N O-rings and Seals
Couldn't load pickup availability
- FREE SHIPPING to The Contiguous United States! (Excluding Alaska & Hawaii)
- Found a Better Price? Contact Us, We'll See if We Can Get You a Better Deal!
- In Stock & Ships from The United States FAST!
- For Quantity Discounts Contact Us for a Quote!
- Customers Outside The Contiguous United States, Please Contact Us for a Quote!
- Call: 1 (760) 598-0189
- Email: hctivista@gmail.com
7CP6110CSG1 Cat Pressure Washer Triplex Positive Displacement Pump 10 GPM 2000 PSI , Gearbox Mounts to a 1" Gas Engine Shaft , Brass Block , Buna-N O-rings and Seals
Cat Pumps 7CP6110CSG1 Triplex Plunger Pump With Gearbox
The Cat Pumps 7CP6110CSG1 is an industrial-duty, triplex positive displacement plunger pump engineered for rigorous, continuous-duty liquid transfer and high-volume cleaning systems. Constructed with a high-strength forged brass manifold and precision-machined 304 stainless steel valve assemblies, this pump offers excellent structural integrity and corrosion resistance in demanding commercial environments. Its internal components feature high-density, polished solid ceramic plungers that provide a true concentric wear surface to minimize friction and heat, significantly extending seal life and ensuring reliable operation under heavy loads.
Engineered specifically for direct-drive gas systems, this unique model comes equipped with a pre-installed, bolt-on gearbox designed to mount directly to standard 1-inch horizontal gas engine shafts. This integrated gearbox effectively reduces the engine's standard 3400 RPM to an optimal internal pump speed, allowing the unit to deliver an exceptional high-volume flow rate of exactly 10 GPM at a maximum operating pressure of 2,000 PSI. Utilizing an oil-bath crankcase design for maximum lubrication and standard NBR (Buna-N) seals, it provides robust, long-lasting performance. This distinct combination of high flow capacity, compact drive configuration, and durable construction makes it a highly preferred, industry-standard component for high-output pressure washers, fleet wash systems, agricultural sprayers, and heavy-duty industrial washdown equipment.
| Specification | Details |
|---|---|
| Model Number | 7CP6110CSG1 |
| Manufacturer | Cat Pumps |
| Pump Type | Triplex Plunger Pump (Positive Displacement) |
| Manifold Material | Forged Brass |
| Valve Assembly Material | 304 Stainless Steel |
| Max Flow Rate | 10.0 GPM (38.0 lpm) |
| Max Operating Pressure | 2000 PSI (138 bar) |
| Engine RPM | 3400 RPM |
| Drive Type | Gearbox (1" Engine Shaft) |
| Max Liquid Temp | 140°F (60°C) |
| Inlet Port Size | (2) 3/4" NPT(F) |
| Discharge Port Size | (2) 1/2" NPT(F) |
| Crankcase Capacity | 38 oz (1.15 L) |
